Precision collet chuck SK30 (DIN 69871) / M12 for ER40
€45.90*
% €54.50* (15.78% saved)Prices incl. 19% VAT. plus Shipping costs
Delivery time: 1-3 working days **
Less than 10 pieces available (online and in specialist shops)
Intended use
ER collet chucks, when used in conjunction with the appropriate collet, enable the secure and rapid clamping of tools with cylindrical shanks. The use of collet systems ensures high concentricity of the respective tool.
Technical data
| Concentricity Inner taper max. [mm]: | 0,002 |
|---|---|
| Hardness [HRC]: | 56 - 58 |
| System accuracy max. [mm]: | 0,005 |
| Tool holder: | SK30/M12 (DIN 69871) |
System accuracy (collet in collet chuck): 0.005 mm
Concentricity of inner cone: 0.002 mm
Material: case-hardened steel, SCM415 / 20CrMnTi
Chemically nickel-plated
Ground and hardened, polished internal cone
Description of the
The electroless nickel plating of this collet chuck achieves a very high surface quality. The other advantages of electroless nickel plating are excellent corrosion protection and very high wear resistance and therefore a long service life. As the inner cone is polished, a high system accuracy (collet in collet chuck) of a maximum concentricity deviation of 0.005 mm is achieved or guaranteed.
In order to maintain this very high concentricity, we recommend using this collet chuck with the appropriate precision collet.
Scope of delivery
- 1 x SK30/M12 precision collet chuck for ER40
- 1 x measurement report
More about the brand and products from
Further information on our professional line
11 December 2023 17:12
Spannfutter SK30 und die Spannzange sind sehr
Spannfutter SK30 und die Spannzange sind sehr hochwertig. Lieferung sehr schnell. Bin vollauf zufrieden. 5Sterne!
13 April 2021 00:00
Sehr präzise Reduzierhülse.
Sehr schönes Zangenfutter, sehr genau rundlaufend, alle Kanten sind entgratet, fast nicht zu glauben, dass es zu einem solch niedrigen Preis verkauft werden kann.
